Hörmann photocell pair EL 301

Discover the Hörmann EL 301 Photocells

The Hörmann EL 301 photocells are advanced safety devices designed to ensure optimal protection for your automated doors and gates. Equipped with a high-performance infrared system, they detect obstacles to stop or reverse movement, effectively preventing accidents and material damage.

Thanks to their robust design and resistance to outdoor conditions, they easily integrate into all types of environments, whether residential or industrial installations.

Suitable for indoor and outdoor installations, they offer a detection range of up to 30 meters and are perfectly weather-resistant, thanks to their IP65 protection rating. They are ideal for both residential and commercial applications.

Compatibility and Applications

The Hörmann EL 301 photocells are specifically designed to work with a wide range of Hörmann motorizations, including:

• Garage Doors: SupraMatic, ProMatic, RollMatic
• Swing Gates: RotaMatic P, PL
• Sliding Gates: LineaMatic P, H

Note: The photocells are only compatible with these motorizations starting from Series 2! If you have a Series 1 motorization, you will need the EL 31 photocells.

Unlike most photocells for gates and garage doors, these EL 301 photocells are not compatible with motorizations from other brands.

Technical Specifications

• Reference : 436233
• Power Supply: 24 V DC
• Range: Up to 30 meters in open field
• Protection Rating: IP65, weather-resistant
• Consumption: 50 mA
• Dimensions: Compact (50 x 90 x 30 mm) for easy installation
• Operating Temperature: -20 °C to +55 °C
• Cables Included: Two 10-meter connection cables
• Manual: Provided

Key Features

• Maximum Safety: Reliable obstacle detection using a precise infrared beam.
• Extended Compatibility: Ideal for Hörmann motorizations, with easy integration.
• Durability: Weather-resistant, perfect for outdoor use.
• Simplified Installation: Easy alignment and quick setup.
• Optimal Range: Detection over a distance of up to 30 meters.

Why Choose Hörmann EL 301 Photocells?

• Safety and Reliability: Effectively prevent accidents with responsive detection.
• Durable Design: Reliable operation even in challenging weather conditions.
• Versatility: Perfect for residential, commercial, or industrial installations.
• Performance: Precise detection and interference-free operation.

Order the Hörmann EL 301 Photocells Today

Ensure the safety of your automated doors and gates with the Hörmann EL 301 photocells. Order them today to enjoy a reliable, high-performance, and easy-to-install product.
